QxP Portable Waveform Monitor
Technology to Power Change
NAB Show 2023, Booth #C4920
Designed for all production workflows, whether HD, UHD, SDR, HDR, SDI or IP, remote or conventional, the QxP’s combined waveform monitor, generator and analyzer toolsets are designed to meet the ever-changing demands of today’s hybrid environments.
Inheriting the flexible architecture of the acclaimed QxL rasterizer, the QxP offers an integral 3U multi-touch LCD screen with integral V-Mount or Gold-mount® battery plates for portability.
- 3U Instrument with integral 1920 x 1200, 7 inch LCD Touch Screen
- V-mount/G-mount® Battery Plate for external battery and portable operation
- Fully flexible instrument display layout, external HDMI rasterizer output with up to 16 simultaneous instruments
- Class leading, patented waveform technology
- As standard: picture view, waveform monitor, vectorscope, extensive audio metering, Dolby ® E/D/D+/ED2 format detection, ANC status and payload, closed captions and Ancillary Time Code, loudness monitoring, remote operator GUI access over noVNC and a full REST API
- Support for HD/2K, UHD/4K, SDR, HDR, SDI and eUHD formats within ST 2110
- In-field upgrades available include: UHD/4K, IP-MEAS, HDR, DOLBY® E Decoder & Metadata Analyzer, PCAP capture and EUHD
- 25G-IP/10G-IP Audio & Video Generation and Analysis
- 12G-SDI Physical Layer Analysis & Stress
- Extensive AMWA NMOS IS-04, IS-05 support and a comprehensive suite of operator level IP flow health and PTP monitoring tools
- Ideal for both on-set and in-studio SDR or HDR productions, post-production, grading, shading, or QC, MCR, engineering and R&D environments
